Beer Filling Line
BG machinery was founded over 12 years ago as a manufacturing operation focused on producing high-quality, durable beer equipment for bars and breweries. The founder --- Mr. Hao, a veteran of mechanical manufacturing and passionate brewer himself, had a vision of creating equipment that would help other brewers achieve their craft with ease and efficiency.
Why Choose Us
Professional Team
With a dedicated team of engineers, designers, and craftsmen, we're constantly pushing the envelope on what's possible in beer equipment design, delivering cutting-edge products that help brewers create the perfect brew every time.
High-Quality Materials
Our beer equipment is made of food-grade stainless steel, which is durable, corrosion-resistant and hygienic. It meets the quality requirements of food and beverage production and ensures the quality of beer.
Production Equipment
We pride ourselves on having state-of-the-art production equipment to craft high-quality beer equipment. Here is a list of some of the equipment that we have in our production facility: Laser cutting machines，CNC bending machines，Welding stations，Polishing equipment，Electrical control systems，Pressure testing equipment，QC testing system.
Customized Design
We can customize beer equipment according to your specific brewing needs, including size, capacity, and configuration, to ensure a perfect fit for your brewery.
Technical Parameters
|
Model |
BGF 16-12-6 |
BGF 18-18-6 |
BGF 24-24-8 |
BGF 32-32-10 |
BGF 40-40-12 |
BGF 50-50-15 |
|
Washing heads |
16 |
18 |
24 |
32 |
40 |
50 |
|
Filling heads |
12 |
18 |
24 |
32 |
40 |
50 |
|
Capping heads |
6 |
6 |
8 |
10 |
12 |
15 |
|
Capacity(BPH) |
2000 |
4000 |
6000 |
10000 |
15000 |
18000 |
|
Power(KW) |
3.5 |
4 |
4.8 |
7.6 |
8.3 |
9.6 |
|
Dimension(mm) |
2200x1600x2400 |
2450x1900x2400 |
2750x2250x2400 |
4000x2300x2400 |
4550x2650x2400 |
5450x3210x2400 |
Advantages of Beer Filling Line
Improve production efficiency
Automatic beer filling equipment can realize automated production, greatly improve production efficiency and shorten production cycle. The equipment can work continuously and stably without manual intervention, reducing production time and increasing output.
Ensure beer quality
The automatic filling equipment adopts isobaric filling technology and precise control system to ensure uniform filling volume of each bottle of beer, avoid pollution and waste, and ensure the quality and taste of beer. In addition, the equipment is equipped with a high-pressure foaming device to discharge oxygen from the bottle mouth, reduce the oxygen content in the bottle, and extend the shelf life of beer.
Reduce labor costs
Automatic filling equipment reduces manual operation and reduces dependence on manual labor, thereby reducing labor costs. The equipment can work continuously, reducing the work intensity and time of workers, and further reducing labor costs.
Improve the working environment
The introduction of fully automatic equipment reduces the tediousness and danger of manual operation and improves the working environment of workers. The design of the equipment itself also takes into account the requirements of environmental protection and energy saving, which helps to improve the environmental quality of the entire production workshop.
Flexibility and scalability
Modern fully automatic beer filling equipment usually adopts modular design, which is convenient for subsequent upgrades and maintenance. The equipment can be quickly adjusted according to market demand and production plans, including changing the filling volume, changing bottle specifications, etc.
Intelligent management
The fully automatic beer filling equipment is equipped with an advanced intelligent management system, which can monitor the operating status and production data of the equipment in real time. Through data analysis, enterprises can optimize production processes, improve production efficiency and reduce production costs. The equipment also supports remote monitoring and operation, which is convenient for enterprises to carry out production management and scheduling.
Energy saving and environmental protection
The fully automatic beer filling equipment adopts advanced energy-saving technologies such as variable frequency speed regulation and centralized lubrication, which effectively reduces energy consumption. The equipment is also equipped with a wastewater treatment system to reduce pollution to the environment.
Beer Filling Line Process
Empty bottle cleaning and disinfection
Before filling, empty beer bottles need to be strictly cleaned and disinfected. This process is usually completed by an empty bottle washing machine, which uses high-pressure water flow and detergent to thoroughly remove stains and impurities inside and outside the bottle, and disinfects them by high-temperature steam or ultraviolet rays to ensure the cleanliness and hygiene of the bottle.
Beer filling
The cleaned and disinfected bottles are conveyed to the filling machine. The filling machine extracts the fermented beer from the fermentation tank through a precise metering system, and after filtering and cooling, it is injected into each bottle at a stable flow rate. In order to ensure the foam stability and taste of the beer, the temperature and pressure of the beer are controlled during the filling process to avoid excessive foam.
Capping and detection
After filling, the beer bottle will be immediately sent to the capping machine for sealing. The capping machine uses a mechanical arm to accurately place the bottle cap on the bottle mouth and use pressure to fix it tightly on the bottle. At the same time, the production line is also equipped with an automatic detection system to perform real-time detection of the sealing of the bottle cap to ensure that each bottle of beer will not leak.
Labeling and packing
After the capping is completed, the beer bottle will enter the labeling machine for labeling. The labeling machine can accurately attach labels with brand logos, production dates and other information to the bottle according to the preset program. Subsequently, the beer bottles will be sent to the packing machine for packaging to form uniform finished boxes ready for shipment to the sales market.
After Sales Service
Installation
We can dispatch our expert technicans to install beer filling line. Service charge includes installation fee, travel expenses and meals.
Training
For getting the best glass bottle beer filling line performance, we offer on-site or at your factory training to dealers, machine operators, engineers and technicians.
Warranty
Provide efficient service, one year quality guarantee period, parts supply and quick feedback troubleshooting when glass bottle beer filling line maintenance.
Consulting
We provide free consulting. Professional sales will give you the most suitable solution. CAD drawing design of beer filling line will be provided.
Technical Support
Offer 24/7 long life technical support. Just mail or give us a call, we will give quick feedback ASAP. Let you be free of worries.
Spare Parts
We will provide a set of spare parts in beer filling line for free when shipping. Full-series quality parts can be ordered at any time with very reasonable price.
Certificate
FAQ
We're professional beer filling line manufacturers and suppliers in China, specialized in providing high quality products and service. We warmly welcome you to buy high-grade beer filling line for sale here from our factory. Contact us for more details.
